7.12 Analog Output Trim
FUS1010 IP65 NEMA 4X & IP66 NEMA 7
Operating Instructions, 01/2013, A5E02951520-AC
133
7.12 Analog Output Trim
Introduction
Analog Out Trim function allows you to fine-tune the flow meter’s analog voltage and current
outputs using an ammeter connected to the output under test. In addition, you can use a
frequency counter to fine-tune the flow meter’s pulse rate output.
Note
The current, voltage, and
Pgen trimming will be limited by the 12-bit resolution of the flow
meter’s D/A Convertor (DAC).
1. From the [Meter Facilities] menu, scroll to the [Analog Out Trim] menu.
2. Press the <Right Arrow> to access the option list.
0HWHU)DFLOLWLHV
6LHPHQV 'XDO3DWK>@3DWK
$QDORJ2XWSXW7ULP
3UHIHUUHG8QLWV  (QJOLVK
7DEOH6HWXSV
/RJJHU&RQWURO
0HPRU\&RQWURO
$QDORJ2XW7ULP
57'&DOLEUDWH
&ORFN6HW

566HWXS 1RQH>@
%DFNOLJKW2Q
6\VWHP,QIR
Table 7- 10 Analog Out Trim Menu Structure
Io1 / Io2 Operate
Trim@4mA Indicated mA=x.xx
Analog Out Trim
Vo1 / Vo2 Operate
T
rim@2V Indicated V=x.xx
Pgen1 / Pgen2
Operate
Trim@1kHz Indicated Hz=x.xx
