8
Alarm, error, and system messages
8.1 Alarm Codes
The following alarm codes appear on the main display of the flow meter.
Table 8- 1 Alarm Codes and Descriptions
Letter Codes Alarm Code Description
SPACE Spacing Sensor spacing may need adjustment
EMPTY Empty Pipe is empty
HI / LO Rate Flow above High setting or below Low setting
FAULT Fault Three continuous seconds without new data update
AER Aeration Current aeration percentage exceeds the alarm set point
MEMRY Memory Last valid reading for a selected interval during Fault condition
MAKUP Makeup In-Process Makeup occurred
The following alarm codes appear in the Datalogger status messages:
I Interface Liquid Vs exceeds interface alarm set point
P Pig Pig passage detected (optional)
Z ZeroMatic ZeroMatic signal occurred
The displays shown below indicate where the Alarm Codes appear on the screen. Press
<UP> or <DOWN> Arrows to change screen views.
)$8/7
63$&(
0$.83
6LHPHQV &KDQQHO>@ 8QLW
)/2:*$/0,1
727$/ *$/ 9V
14.35
354.6597 14.27
100.0
0.0
31.74
9I
① Alarm Codes
FUS1010 IP65 NEMA 4X & IP66 NEMA 7
Operating Instructions, 01/2013, A5E02951520-AC
153
