Functions
7.5 Analog Out Setup
FUS1010 IP65 NEMA 4X & IP66 NEMA 7
Operating Instructions, 01/2013, A5E02951520-AC
115
7.5 Analog Out Setup
The flow meter provides current, voltage and pulse-rate analog outputs. The [Analog Out
Setup] menu allows you to assign data functions for these signals. The transmitter terminal
strip contains the analog output terminals.
Table 7- 3 Analog Outputs
Io (Isolated Current) 4 to 20mA varies in proportion to an assigned
data function.
Vo (DC Voltage 0 to 10 VDC varies in proportion to an assigned
data function.
Pgen (TTL Logic) 0 to 5000 Hz varies in proportion to an assigned
data function.
Table 7- 4 Analog Out Setup Data Categories
Vfo Spanned volumetric/mass flow
Vfab Spanned unsigned flow magnitude
Vs Spanned liquid sonic velocity
Valc Receive signal amplitude
Vaer Relative degree of liquid aeration/cavitation
Viscosity System liquid viscosity
T1 Current liquid temperature.
Iin1, Iin2 Represents a re-transmit of the analog input
signals (e.g. Pressure and Temp inputs can be
transmitted on the 4/20mA output).
Iin3, Iin4 Same as Iin1 and Iin2 above but only available
for operation in Multi-Path and Arithmetic modes.
Note
Refer to Appendix A (Page 181) for Analog output connections in
cluding connections multi-
channel meters.
