Connecting
5.6 Mounting Temperature Sensors
FUS1010 IP65 NEMA 4X & IP66 NEMA 7
78 Operating Instructions, 01/2013, A5E02951520-AC
10. This time, before installing each sensor, apply a 3mm (1/8-inch) continuous bead of
couplant compound along the center (the long way) of the contact surface of the sensor.
Also, keep the sensors lifted slightly from the pipe when installing until the sensor is
against the pin; then push down against the pipe.
Note
Remember to install the sensors with the cable connectors facing away from each other.
11. Once the sensors are in place, secure with its clamping screws. Do not over tighten.
12. Observing the upstream and downstream orientation, attach the UP (upstream) and DN
(downstream) cables to the sensors and make snug. Attach the other ends to the UP and
DN terminals of the flow meter.
13. Proceed to Commissioning (Page 83).
5.6 Mounting Temperature Sensors
Temperature is used to normalize the liquids sonic velocity in order to properly determine
interfaces and for density determination. Temperature sensors are available in clamp-on
style or in insert (Thermowell) style. Refer to the table below. Both styles incorporate 1000
ohm platinum RTD’s for high precision.
Table 5- 3 Temperature Sensors
Description Part Number
Standard clamp-on RTD 7ME39501TA00
Submersible clamp-on RTD (not for FUP1010 or FUE1010 7ME39501TB00
Standard clamp-on RTD pair for FUE1010 energy system 7ME39501TA10
Insertion style RTD (size 1): 140mm (5.5 in) 7ME39501TJ00
Insertion style RTD (size 2): 216mm (8.5 in) 7ME39501TJ01
Insertion style RTD (size 3): 292mm (11.5 in) 7ME39501TJ02
Insertion style RTD (size 4): 368mm (14.5 in) 7ME39501TJ03
Insertion style RTD pair (size 1) for FUE1010, 140mm (5.5
in)
7ME39501TJ10
Insertion style RTD pair (size 2) for FUE1010, 216mm (8.5
in)
7ME39501TJ11
Insertion style RTD pair (size 3) for FUE1010, 292mm (11.5
in)
7ME39501TJ12
Insertion style RTD pair (size 4) for FUE1010, 368mm (14.5
in)
7ME39501TJ13
