A
Appendix
A.1 Ordering
In order to ensure that the ordering data you are using is not outdated, the latest ordering
data is always available on the Internet: Catalog process instrumentation
(http://www.siemens.com/processinstrumentation/catalogs
)
See also
Process instrumentation catalog (http://www.siemens.com/processinstrumentation/catalogs)
A.2 I/O Connections and Wiring
Terminal Block Wiring - 7ME39400AL00 and 7ME39400AL01 I/O Module
(Refer to manual drawing 1010N-2-7 sheet 2 of 2)
These connection diagrams apply to the part numbers listed below.
Table A- 1 Connection Diagrams and Part Numbers
1010N-2-7 (Sheet 2 of 2) Drawing
FUS1010 7ME3530, 7ME3533
FUE1010 7ME3500
FUH1010 7ME3600, 7ME3603
FUS1010 IP65 NEMA 4X & IP66 NEMA 7
Operating Instructions, 01/2013, A5E02951520-AC
181
