Commissioning

6.4 Installation Menus

FUS1010 IP65 NEMA 4X & IP66 NEMA 7

88 Operating Instructions, 01/2013, A5E02951520-AC

6HW(PSW\



6LHPHQV &KDQQHO>@$%&

6HW(PSW\3LSH'HWHFWLRQ7KUHVKROG

,QVWDOO6HQVRU

6HQVRU0RGHO +37

6HQVRU6L]H '+

6HQVRU0RXQW0RG 

6SDFLQJ2IIVHW  

1XPEHU,QGH[ 

6SDFLQJ0HWKRG 6SDFHU%DU%1

/WQ9DOXHLQ 

(PSW\3LSH6HW 07<PDWLF

=HUR)ORZ$GMXVW $FWXDO07<

,QVWDOO&RPSOHWH !6HW(PSW\

4. Press <ENTER>. The current empty threshold number appears in a pop-up window.

5. Use the numeric keys to type a new Set Empty number.

6. To store the Set Empty number press <ENTER>

6.4 Installation Menus

FUS1010 Installation Menu Chart

Use <Left>, <Right>, <Up> and<Down> arrow buttons to navigate the menu between levels

and sub menus.

For example: To navigate to [Sensor Size]:

1. Press <MENU> to return to Level A.

2. Press <Right Arrow> to Level B (2 Channel Flow) then press <ENTER>.

3. Scroll using <Down Arrow> to [Install Sensor].

4. Press <Right Arrow> to Level D.

5. Scroll using <Down Arrow> to [Sensor Size].

6. Press <ENTER> select size from list.

Note

Menu items in bold are required entries to establish operation.
