Commissioning
6.3 Empty Pipe Set
FUS1010 IP65 NEMA 4X & IP66 NEMA 7
Operating Instructions, 01/2013, A5E02951520-AC
87
Using the MTYmatic command
You can repeat MTYmatic (performed during the Initial Makeup) to correct an inaccurate
Actual MTY setting if conditions do not allow you to repeat the Actual Empty procedure.
Note
IM
PORTANT
Only use the MTYmatic procedure when the pipe is full.
To start MTYmatic:
1. From [Channel Setup] scroll down to [Install Sensor].
2. Press the <Right Arrow> to access the [Empty Pipe Set] option list.
6LHPHQV &KDQQHO>@$%&
6HW(PSW\3LSH'HWHFWLRQ7KUHVKROG
,QVWDOO6HQVRU
6HQVRU0RGHO +37
6HQVRU6L]H '+
6HQVRU0RXQW0RGH 5HIOHFW
6SDFLQJ2IIVHW 1RUPDO
1XPEHU,QGH[
6SDFLQJ0HWKRG 6SDFHU%DU%1
/WQ9DOXHLQ
(PSW\3LSH6HW !07<PDWLF
=HUR)ORZ$GMXVW $FWXDO07<
,QVWDOO&RPSOHWH 6HW(PSW\
3. Move the cursor next to [MTYmatic] press the <Right Arrow>.
4. To invoke MTYmatic press <ENTER>.
Using the Set Empty command
Use [Set Empty] to enter a number that represents the signal strength level consistent with
an empty pipe. [Set Empty] uses non-linear scaling. There is no direct correlation between
the number you enter and any standard amplitude unit. If you set the number too low, the
meter may not detect a true empty pipe. If you set it too high, it could trigger the empty pipe
alarm, suspending flow measurement, even though the liquid is flowing.
To enter an Empty Pipe Alarm Threshold:
1. From [Channel Setup] scroll down to [Install Sensor].
2. Press the <Right Arrow> to access the [Empty Pipe Set] option list.
3. Press <Up Arrow> to move the cursor to [Set Empty].
To Next Page
