6.3 Empty Pipe Set
FUS1010 IP65 NEMA 4X & IP66 NEMA 7
86 Operating Instructions, 01/2013, A5E02951520-AC
3. Press the <Down Arrow> to [Actual MTY] then press <ENTER>.
– Empty Pipe Press [ENT] appears on the menu prompt line.
6LHPHQV &KDQQHO>@$%&
(PSW\3LSH 3UHVV>(17@
,QVWDOO6HQVRU
6HQVRU0RGHO +37
6HQVRU6L]H '+
6HQVRU0RXQW0RGH 5HIOHFW
6SDFLQJ2IIVHW 1RUPDO
1XPEHU,QGH[ 
6SDFLQJ0HWKRG 6SDFHU%DU%1
/WQ9DOXHLQ 
(PSW\3LSH6HW 07<PDWLF
=HUR)ORZ$GMXVW !$FWXDO07<
,QVWDOO&RPSOHWH 6HW(PSW\
4. Empty the pipe completely, then press <ENTER>.
– Fill Pipe Press [ENT] appears on the menu prompt line.
6LHPHQV &KDQQHO>@$%&
)LOO3LSH  3UHVV>(17@
,QVWDOO6HQVRU
6HQVRU0RGHO +37
6HQVRU6L]H '+
6HQVRU0RXQW0RGH 5HIOHFW
6SDFLQJ2IIVHW 1RUPDO
1XPEHU,QGH[ 
6SDFLQJ0HWKRG 6SDFHU%DU%1
/WQ9DOXHLQ 
(PSW\3LSH6HW 07<PDWLF
=HUR)ORZ$GMXVW !$FWXDO07<
,QVWDOO&RPSOHWH 6HW(PSW\
5. Refill the pipe completely, then press <ENTER>.
