10.3 Test Facilities Graph Screen
FUS1010 IP65 NEMA 4X & IP66 NEMA 7
Operating Instructions, 01/2013, A5E02951520-AC
171
Table 10- 3 Hot Key Summary
Key Command Line Description
<+> Expands (magnifies) waveform to view
more detail.
<-> Contracts waveform to view more of
the waveform.
<Left Arrow> Shifts receive window to the left
(waveform to the right).
<Right Arrow> Shifts receive window to the right
(waveform to the left).
<CLR> Brings waveform to the center of the
screen.
<ENTER> Calls up Text Display menu items.
<Left Arrow> to return to graph.
<MENU> Exits the Graph Screen and returns to
the main menu.
<1> MinDamp Minimum damping exponent control (+
or - to increase or decrease).
<2> MaxDamp Maximum damping exponent control (+
or - to increase or decrease).
<3> TnSet Transit time adjustment (use + or - to
move Tn marker).
<4> ZCOSet Zero Crossover adjustment (use + or -
to move crossover marker).
<5> HiSet Signal envelope threshold level (use +
or - to move threshold).
<6> LoSet Signal envelope threshold level (use +
or - to move threshold).
<7> MaskSet Leading edge masking functions (use +
or - to alter number of samples
masked).
<8> Hold Set Set this number higher if intermittent
mis-registration occurs.
<0> Exits the command line.
<=> Toggle graph between receive
waveform and envelope waveform.
<F1> and <.> Dumps the digitized waveform data
over the RS-232 port. You must first
leave the Graph Screen mode before
invoking this command.
