Siemens FUS1010 - Figure 5-26 Clamp-On Temperature Sensor

Connecting
5.6 Mounting Temperature Sensors
FUS1010 IP65 NEMA 4X & IP66 NEMA 7
Operating Instructions, 01/2013, A5E02951520-AC
79





① 7ME39600CR 992EC Series Cable ③ Thermal Couplant
② Clamp-on Temperature Sensor (Matched
pair required for FUE1010)
④ Pipe
⑤ Mounting Assembly
Figure 5-26 Clamp-on Temperature Sensor
