Functions
7.8 Logger Control
FUS1010 IP65 NEMA 4X & IP66 NEMA 7
124 Operating Instructions, 01/2013, A5E02951520-AC
7.8 Logger Control
Logger Control Menu
The Logger Control menu in the [Meter Facilities] menu provides the Logger controls for the
flow meter measurement channels and paths. It allows the user to select data items/alarm
events, a logging interval and a destination for Logger reports. While the Logger Setup menu
is measurement channel/path specific, this Logger Control menu provides global control
functions. This means that the settings made here apply to all measurement channels/paths,
meter types, operating modes, etc. This is possible because the flow meter stores logged
data in a single file.
The [Est LogTime Left] menu view-only menu cell shows an estimate of the hours and
minutes of logging time remaining. For convenience sake, the Display Logger command is
essentially a duplicate of the menu cell in Logger Setup. It sends Logger data to the graphic
screen with or without line wrapping. The Output Logger command sends data to an external
device via the RS-232 serial port. The Clear Logger command erases the entire Logger file.
1. From the Meter Facilities menu access the [Logger Control] menu by pressing the <Right
Arrow>.
2. Scroll down to [Logger Control]. Press the <Right Arrow> to access the [Logger Control]
menu option list.
0HWHU)DFLOLWLHV
6LHPHQV 'XDO3DWK>@3DWK
'DWDORJJHU&RQWURO
3UHIHUUHG8QLWV (QJOLVK
7DEOH6HWXSV
/RJJHU&RQWURO
0HPRU\&RQWURO
$QDORJ2XW7ULP
57'&DOLEUDWH
&ORFN6HW

566HWXS 2GG>@
%DFNOLJKW 2Q
6\VWHP,QIR
Table 7- 7 Logger Control Menu Option List
Display Logger Off
Line Wrap
No Line Wrap
Logger Control
Output Logger No
Yes
Circular Memory (Available for
Multi-Path units only)
No
Yes
Est LogTime Left --:--
Clear
Logger No
Yes
