Installing/mounting
4.5 Mounting the Transmitter
FUS1010 IP65 NEMA 4X & IP66 NEMA 7
Operating Instructions, 01/2013, A5E02951520-AC
35
4.5 Mounting the Transmitter
WARNING
Hazardous Voltage
May cause death or serious personal injury.
Disconnect power before working on this product.
Wall Mounting
The transmitter can be mounted on any wall surface including wood, metal or concrete. Use
the appropriate bolts and screws as needed for your mounting application and adhere to
local codes. (See figure below for mounting bracket locations.)
Pipe Mounting
For installation on 2-inch (6 cm) mounting pipe use Pipe Mount Kit CQO:1012NMB-1
(optional - see catalog). See figure below.
Note
Pipe mountin
g kit CQO:1012NMB-1 is not available for IP66 NEMA 7 enclosures.
