Connecting
5.2 Transmitter Wiring
FUS1010 IP65 NEMA 4X & IP66 NEMA 7
Operating Instructions, 01/2013, A5E02951520-AC
39
WARNING
Electrical Voltage Hazard
Incorrect device connections may result in death or severe personal injury and/or
equipment and property damage.
Only commission the device after the device has been properly connected and, if
required, closed.
5.2 Transmitter Wiring
5.2.1 Connecting Power
Connecting Power
DANGER
Electrical Shock Hazard
Contact with exposed wiring will lead to fire, electric shock, or serious personal injury.
Turn off main power before installing AC connections to the transmitter.
Note
If the transmitter is not already mounted and cabling has not been run, proceed to Mounting
the Tran
smitter (Page 35) before connecting power.
1. Open the transmitter top cover by releasing the cover latch (for IP66 NEMA 7, remove
bolts).
2. Unscrew the two power supply access cover fasteners and remove access cover.
3. Locate power supply connector J10. Using a flat blade screwdriver, remove plug from
connector J10. Set aside.
To Next Page
