Siemens FUS1010 User Manual

Commissioning
6.4 Installation Menus
FUS1010 IP65 NEMA 4X & IP66 NEMA 7
Operating Instructions, 01/2013, A5E02951520-AC
89
Level A Level B Level C Level D (see
manual)
Level E Level F
Meter Type 2 Channel
Flow
Chan/1/2 Clamp-
on
Recall Site Setup Enter From List
Dual Path
Flow
⇓ Channel Enable No/Yes
Ch 1+2 Flow Channel Setup ⇒ Create/Name Site Enter From List
Ch 1-2 Flow Site Security On/Off
Reflexor Delete Site Enter From List
Save/Rename
Site
Enter/Clear Site Name
Pipe Data Pick Pipe Class Enter From List
Select Pipe Size Enter From List
Pipe OD (in) Numeric Entry
Pipe Material Enter From List
Wall Thickness Numeric Entry
Liner Material Enter From List
Liner Thickness Numeric Entry
Application Data Liquid Class Select Liquid Enter From List
Estimated Vs M/S Numeric Entry
Viscosity <cS> Numeric Entry
Density S.G. Numeric Entry
UniMass Table Enter From List
Temp. Range Enter From List
Pipe Config Enter From List
Anomaly Diams Numeric Entry
Install Sensor Sensor Model Enter From List
Sensor Size Enter From List
Sensor Mount
Mode
Enter From List
Spacing Offset Enter From List
Number Index View Only
Spacing Method View Only
Ltn Value <in> View Only
Install Complete No / Install Select Install
Empty Pipe Set Enter From List
Zero Flow Adjust Enter From List
Operation Adjust Damping Control Time Average / SmartSlew
Deadband Control Numeric Entry
Memory/Fault Set Fault / Memory
Memory Delay (s) N/A
Flow Total Units Flow Vol. Units Enter From List
Flow Time Units Enter From List
