Functions

7.12 Analog Output Trim

FUS1010 IP65 NEMA 4X & IP66 NEMA 7

134 Operating Instructions, 01/2013, A5E02951520-AC

Current Output Trim (Io1 & Io2)

Note

Can be trimmed to within .005mA of nominal.

To calibrate a current output:

1. Set up an ammeter to read Amps, then connect it to the supply and return terminals of

the current output under test.

2. Move the highlight to the port to be tested by pressing the <Up/Down Arrow>. Press the

<Right Arrow> and then press the <Down Arrow> to move the cursor to [Trim @ 4mA].

$QDORJ2XW7ULP

6LHPHQV 'XDO3DWK>@3DWK

7ULPP$RXWSXW

7ULP,R !2SHUDWH

7ULP,R

 7ULP#P$

7ULP9R 2SHUDWH

7ULP9R 2SHUDWH

7ULP3JHQ 2SHUDWH

7ULP3JHQ 2SHUDWH

3. Press <ENTER>. This triggers a 4.00mA pop-up window. The ammeter should now be

reading 4.00mA.

4. If the ammeter reading does not match, use the numeric keys to type in the current

reading.

5. Press <ENTER> to register setting. This adjusts the flow meter’s DAC (digital-to-analog

converter) so that a 4mA output corresponds with 4mA on the ammeter.

6. Re-check the ammeter to make sure that it is now reading 4mA.
