Functions
7.14 Reflexor
FUS1010 IP65 NEMA 4X & IP66 NEMA 7
Operating Instructions, 01/2013, A5E02951520-AC
141
Selecting Sensor Mounting Location
Select a sensor mounting location that has a fully developed flow profile. Do not locate the
sensor so that sonic energy enters a region that is not representative of the flow velocities at
the measuring location. Use the figure below as a guide to select the proper mounting
location.
① ③ Elbow Valve
② Expansion or Contraction ④ Orifice Plate
Figure 7-2 Sensor Mounting Examples
