Siemens FUS1010 User Manual

Appendix
A.2 I/O Connections and Wiring
FUS1010 IP65 NEMA 4X & IP66 NEMA 7
Operating Instructions, 01/2013, A5E02951520-AC
185
1
2
3
4
5
6
7
8
9
10
11
12
13
14
K1-A
GND
GND
*K1-B
K1-C
K2-A
*K2-B
K2-C
K3-A
*K3-B
K3-C
K4-A
*K4-B
K4-C
TB3
Note
Relays shown in Power OFF position, which is the same as the alarm assertion position.
*7ME39400AL00 Mercury Relay only available with Normally Open.
Terminal Block Wiring - 7ME39400AL03 and 7ME39400AL04 Expanded I/O Module
(Refer to manual drawing 1010N-7-7 sheet 2 of 2)
These connection diagrams apply to the part numbers listed below.
