Description
3.4 Theory of Operation
FUS1010 IP65 NEMA 4X & IP66 NEMA 7
28 Operating Instructions, 01/2013, A5E02951520-AC
2-Channel
Dual Channel provides two independent measurement channels that operate
simultaneously. Depending on the specific model, Dual Channel supports: Clamp-on Transit-
time, In-line Transit-time and Reflexor.
① ⑤ Upstream Sensors Pipe B Output Flow
② Downstream Sensors ⑥ Channel 2 for Pipe B
③ Channel 1 for Pipe A ⑦ Pipe B
④ Pipe A Output Flow ⑧ Pipe A
4-Channel
4 Channel provides four independent measurement channels that operate simultaneously.
Depending on the specific model, 4 Channel supports: Clamp-on Transit-time, In-line
Transit-time and Reflexor.
