Chapter 4
System Administration
RUGGEDCOM ROS
User Guide
120 Configuring User Priviliges
• 1 represents the guest access level
To configure the privilege levels for each user type, do the following:
1. Navigate to Administration » Configure Security Server » Configure TacPlus Server » Configure
TACPLUS Serv Privilege Config. The TACPLUS Serv Privilege Config form appears.
Figure 76: TACPLUS Serv Privilege Config Form
1. Server Box 2. IP Address Box 3. Auth TCP Port Box 4. Apply Button 5. Reload Button
2. Configure the following parameter(s) as required:
Parameter Description
Admin Priv Synopsis: (0 to 15)-(0 to 15)
Default: 15
Privilege level to be assigned to the user.
Oper Priv Synopsis: (0 to 15)-(0 to 15)
Default: 2-14
Privilege level to be assigned to the user.
Guest Priv Synopsis: (0 to 15)-(0 to 15)
Default: 1
Privilege level to be assigned to the user.
3. Click Apply.
