Siemens RUGGEDCOM ROS User Manual

Chapter 5
Setup and Configuration
RUGGEDCOM ROS
User Guide
136 Deleting a Static VLAN
Parameter Description
This parameter is only valid for Multiple Spanning Tree Protocol (MSTP) and has no
effect if MSTP is not used. The parameter specifies the Multiple Spanning Tree Instance
(MSTI) to which the VLAN should be mapped.
4. Click Apply.
Section 5.2.5.3
Deleting a Static VLAN
To delete a static VLAN, do the following:
1. Navigate to Virtual LANs » Configure Static VLANs. The Static VLANs table appears.
Figure 89: Static VLANs Table
2. Select the static VLAN from the table. The Static VLANs form appears.
6
7
8
1
2
3
4
5
Figure 90: Static VLANs Form
1. VID Box 2. VLAN Name Box 3. Forbidden Ports Box 4. IGMP Options 5. MSTI Box 6. Apply Button 7. Delete Button
8. Reload Button
3. Click Delete.
