Chapter 3
Device Management
RUGGEDCOM ROS
User Guide
84 Configuring IP Services
64
5
2
1
3
Figure 45: IP Gateways Form
1. Destination Box 2. Subnet Box 3. Gateway Box 4. Apply Button 5. Delete Button 6. Reload Button
3. Click Delete.
Section 3.9
Configuring IP Services
To configure the IP services provided by the device, do the following:
1. Navigate to Administration » Configure IP Services. The IP Services form appears.
8 9
7
6
5
4
3
2
1
Figure 46: IP Services Form
1. Inactivity Timeout Box 2. Telnet Sessions Allowed Box 3. Web Server Users Allowed Box 4. TFTP Server Box 5. Modbus
Address Box 6. SSH Sessions Allowed Box 7. RSH Server Box 8. Apply Button 9. Reload Button
2. Configure the following parameter(s) as required:
Parameter Description
Inactivity Timeout Synopsis: 1 to 60 or { Disabled }
