Chapter 3
Device Management
RUGGEDCOM ROS
User Guide
64 Displaying Information for an SFP Port
Configured Speed
Detected SFP
Type: 1000Base-X
Detected SFP
Type: 100Base-FX
Detected SFP
Type: 1000Base-T
1 Gbps Accept
Accept and automatically set
the speed to 100 Mbps and
set auto-negotiation to Off
Accept
100 Mbps
Accept and automatically
set the speed to 1 Gbps and
set auto-negotiation to On
Accept
Compare the transceiver model
against a list of supported
models. Accept if it is in the
list. Otherwise, automatically
set the speed to 1 Gbps and
set auto-negotiation to On.
If the transceiver is accepted, the Media parameter under Ethernet Ports » Configure Port Parameters shows
detailed information about the SFP transceiver, including Gigabit Ethernet Compliance Code, transmission media,
connector type, and link length. For example:
SFP 1000LX SM LC 10 km
SFP 1000T 100 m
If the transceiver is not recognized, it is rejected. An alarm is also generated and the port is blocked so that
no link can be established until the transceiver is replaced. The Media parameter shows the rejected SFP
transceiver is unidentified. For example:
SFP Unidentified
If no transceiver is installed on an SFP port, the Media parameter shows the SFP transceiver is unplugged:
SFP Unplugged
Section 3.6.6.3
Displaying Information for an SFP Port
To display detailed information about an SFP port, do the following:
1. Log in to the device and access the CLI shell. For more information about accessing the CLI shell, refer to
Section 2.6, “Using the Command Line Interface”.
2. Type the following command:
sfp port
Where:
• port is the port number
Information about the SFP port is displayed. For example:
>sfp 11/1
ID: SFP
Extended ID: GBIC/SFP function is defined by serial ID only
Connector: LC
Transceiver:
Gigabit Ethernet Compliance Codes:
1000LX
Fibre Channel link length:
Long Distance (L)
Fibre Channel transmitter technology:
Longwave laser (LC)
Fibre Channel transmission media:
Single Mode (SM)
