RUGGEDCOM ROS
User Guide
Chapter 5
Setup and Configuration
Purging All Dynamic MAC Addresses 179
7
5
6
4
3
2
1
Figure 123: Static MAC Addresses Form
1. MAC Address Box 2. VID Box 3. Port Box 4. CoS List 5. Apply Button 6. Delete Button 7. Reload Button
3. Click Delete.
Section 5.5.5
Purging All Dynamic MAC Addresses
To purge the dynamic MAC address list of all entries, do the following:
1. Navigate to MAC Address Tables » Purge MAC Address Table. The Purge MAC Address Table form
appears.
1
Figure 124: Purge MAC Address Table Form
1. Confirm Button
2. Click Confirm.
Section 5.6
Managing Time Services
The System Time Manager offers the following time-keeping and time synchronization features:
• Local hardware time keeping and time zone management
• SNTP (Simple Network Time Protocol) client and server
