RUGGEDCOM ROS
User Guide
Chapter 5
Setup and Configuration
Configuring IEEE 802.1X 221
Parameter Description
Specifies for how long to shut down the port, if a security violation occurs.
Status Synopsis: Any 31 characters
Describes the security status of the port.
NOTE
There are a few scenarios in which static MAC addresses can move:
• When the link is up/down on a non-sticky secured port
• When traffic switches from or to a non-sticky secured port
NOTE
Traffic is lost until the source MAC Address of the incoming traffic is authorized against the static
MAC address table.
4. Click Apply.
Section 5.10.4
Configuring IEEE 802.1X
To configure IEEE 802.1X port-based authentication, do the following:
1. Navigate to Port Security » Configure 802.1X. The 802.1X Parameters table appears.
Figure 168: 802.1X Parameters Table
2. Select an Ethernet port. The 802.1X Parameters form appears.
