212 Configuring GMRP for Specific Ethernet Ports
2. Navigate to Multicast Filtering » Configure Port GMRP Parameters. The Port GMRP Parameters table
appears.
Figure 157: Port GMRP Parameters Table
3. Select an Ethernet port. The Port GMRP Parameters form appears.
Figure 158: Port GMRP Parameters Form
1. Port(s) Box 2. GMRP List 3. Apply Button 4. Reload Button
4. Configure the following parameter(s) as required:
Parameter Description
Port(s) Synopsis: Any combination of numbers valid for this parameter
The port number as seen on the front plate silkscreen of the switch (or a list of ports, if
aggregated in a port trunk).
GMRP Synopsis: { Disabled, Adv Only, Adv&Learn }
Default: Default: Disabled
Configures GMRP (GARP Multicast Registration Protocol) operation on the port. There
are several GMRP operation modes:
• DISABLED - the port is not capable of any GMRP processing.
• ADVERTISE ONLY - the port will declare all MCAST addresses existing in the switch
(configured or learned) but will not learn any MCAST addresses.
• ADVERTISE & LEARN - the port will declare all MCAST Addresses existing in the
switch (configured or learned) and can dynamically learn MCAST addresses.
5. Click Apply.
