Siemens S120 User Manual

Control Units, Control Unit Adapters and operating components
7.4 Control Unit CU310-2 DP (PROFIBUS)
AC Drive
296 Manual, (GH6), 04/2014, 6SL3097-4AL00-0BP4
7.4.2.6
X100 DRIVE-CLiQ interface
Table 7- 27 X100 DRIVE-CLiQ interface
Pin
Signal name
Technical data
1
TXP
Transmit data +
2
TXN
Transmit data -
3
RXP
Receive data +
4
Reserved, do not use
-
5
Reserved, do not use
-
6
RXN
Receive data -
7
Reserved, do not use
-
8
Reserved, do not use
-
A
+ (24 V)
Power supply
B
M (0 V)
Electronic ground
Connector type
DRIVE-CLiQ socket
The blanking cover for the DRIVE
-CLiQ port is included in the scope of delivery.
Blanking covers (50 pieces) Order number: 6SL3066-4CA00-0AA0

Siemens S120 Specifications

General

Communication interfaces	PROFINET, PROFIBUS, Ethernet
Protection features	Overcurrent, overvoltage, overtemperature, short circuit
Storage temperature range	-25°C to +70°C
Relative humidity	5 to 95% (non-condensing)
Enclosure rating	IP20
Cooling method	Air cooling
Operating temperature range	0 to +55 °C
