Accessories
9.4 Shield connection kit
AC Drive
412 Manual, (GH6), 04/2014, 6SL3097-4AL00-0BP4
9.4.3
Mounting
9.4.3.1
PM340 Blocksize Power Modules
The diagrams show the mounting of shield connection kits on PM340 Power Modules with
various frame sizes.
Frame size FSA
Figure 9-25 Mounting: Shield connection kit on PM340 Power Module (FSA)
