4.3 Power Modules Blocksize (PM340)
AC Drive
142 Manual, (GH6), 04/2014, 6SL3097-4AL00-0BP4
4.3.5
Mounting
4.3.5.1
Mounting dimensions and tightening torques
The mounting dimensions and the tightening torques for fixing the Power Modules are
specified in the following table.
Table 4- 21 PM340, dimensions and tightening torques for mounting
Frame size
Height, width, depth
Dimensions
(with Control Unit)
Retaining type
Tightening torques
FSA HxWxD
mm
173 x 73 x 145
2 x M4 studs,
2 x M4 nuts,
2 x M4 washers
2.5 Nm with washers
Inch 6.81 x 2.87 x 5.71
FSB HxWxD
mm
270 x 153 x 165
4 x M4 studs,
4 x M4 nuts,
4 x M4 washers
Inch 10.63 x 6.02 x 6.50
FSC HxWxD
mm
334 x 189 x 185
4 x M5 studs,
4 x M5 nuts,
4 x M5 washers
Inch 13.1 x 7.41 x 7.28
FSD
without line
filter
HxWxD
mm
419 x 275 x 204
4 x M6 studs,
4 x M6 nuts,
4 x M6 washers
6 Nm with washers
Inch 16.3 x 10.8 x 8.0
FSD
with
integrated line
filter
HxWxD
mm
512 x 275 x 204
Inch 20.1 x 10.8 x 8.0
FSE
without line
filter
HxWxD
mm
499 x 275 x 204
Inch 19.6 x 10.8 x 8.0
FSE
with
integrated line
filter
HxWxD mm 635 x 275 x 204
Inch 25 x 10.8 x 8.0
FSF
without line
filter
HxWxD
mm
635 x 350 x 316
4 x M8 studs,
4 x M8 nuts,
4 x M8 washers
13 Nm with washers
Inch 25.0 x 13.8 x 12.4
FSF
with
integrated line
filter
HxWxD
mm
934 x 350 x 316
Inch 36.8 x 13.8 x 12.4

Siemens S120 Specifications

General

Communication interfaces	PROFINET, PROFIBUS, Ethernet
Protection features	Overcurrent, overvoltage, overtemperature, short circuit
Storage temperature range	-25°C to +70°C
Relative humidity	5 to 95% (non-condensing)
Enclosure rating	IP20
Cooling method	Air cooling
Operating temperature range	0 to +55 °C
