Siemens S120 User Manual

Cabinet design and EMC for components, Blocksize format
10.9 Information on control cabinet cooling
AC Drive
448 Manual, (GH6), 04/2014, 6SL3097-4AL00-0BP4
10.9.3.3
Power loss for line reactors and line filters
Table 10- 22 Overview of power loss during rated operation for line reactors and line filters
Rated output current I
rated
Frame size
Line voltage
Unit
Power loss
50/60 Hz
Line reactors for PM240-2 Blocksize
4.0 A FSA (1.1 kW) 1-phase 200 ... 240
VAC
W 23 / 25,3
11.3 A FSA (4.0 kW) 1-phase 200 ... 240
VAC
W 36 / 39,6
22.3 A FSB 1-phase 200 ... 240
VAC
W 53 / 58,3
47.0 A FSC 1-phase 200 ... 240
VAC
W 88 / 96,8
4.0 A FSA (1.1 kW) 3-phase 380 ... 480
VAC
W 23 / 25,3
11.3 A FSA (4.0 kW) 3-phase 380 ... 480
VAC
W 36 / 39,6
22.3 A FSB 3-phase 380 ... 480
VAC
W 53 / 58,3
47.0 A FSC 3-phase 380 ... 480
VAC
W 88 / 96,8
Line reactors for Blocksize PM340
0.9 A / 2.3 A FSA 1-phase 200 ... 240
VAC
W 12,5 / 15
3.9 A FSA 1-phase 200 ... 240
VAC
W 11,5 / 14,5
1.3 A / 1.7 A FSA 3-phase 380 ... 480
VAC
W 6 / 7
2.2 A / 3.1 A FSA 3-phase 380 ... 480
VAC
W 12,5 / 15
4.1 A FSA 3-phase 380 ... 480
VAC
W 7,5 / 9
5.9 A / 7.7 A FSB 3-phase 380 ... 480
VAC
W 9 / 11
10.2 A FSB 3-phase 380 ... 480
VAC
W 27 / 32
18 A / 25 A FSC 3-phase 380 ... 480
VAC
W 98 / 118
32 A FSC 3-phase 380 ... 480
VAC
W 37 / 44
38 A / 45 A / 60 A FSD 3-phase 380 ... 480
VAC
W 90 / 115
75 A / 90 A FSE 3-phase 380 ... 480
VAC
W 170 / 215
110 A / 145 A / 178 A FSF 3-phase 380 ... 480
VAC
W 280 / 360

Siemens S120 Specifications

General

Communication interfaces	PROFINET, PROFIBUS, Ethernet
Protection features	Overcurrent, overvoltage, overtemperature, short circuit
Storage temperature range	-25°C to +70°C
Relative humidity	5 to 95% (non-condensing)
Enclosure rating	IP20
Cooling method	Air cooling
Operating temperature range	0 to +55 °C
