SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
System Manual, 09/2019, C79000-G8976-C242-10
193
SFP992-1LD+ 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 30 km
6GK5 992-1AM30-8AA0
SFP992-1LH 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 40 km
6GK5 992-1AN00-8AA0
SFP992-1LH+ 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 70 km
6GK5 992-1AP00-8AA0
SFP992-1ELH 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 120 km
6GK5 992-1AQ00-8AA0
Pluggable transceivers with the supplement (C) in the type name have varnished printed circuit bo
ards
Bidirectional plug-in transceiver SFP
Bidirectional plug-in transceivers feature only one fiber connection. They transmit and
receive on two different wavelengths. To establish a connection, you need two matching
bidirectional SFPs. The connected SFPs must respectively transmit on the wavelength at
which the connection partner receives.
SFP992-1BXMT 1 x 1000 Mbps LC port optical for glass FO
(multimode) with max. 500 m, transmits at 1550
6GK5 992-1AL00-8TA0
SFP992-1BXMR 1 x 1000 Mbps LC port optical for glass FO
(multimode) with max. 500 m, transmits at 1310
6GK5 992-1AL00-8RA0
SFP991 interfaces (100 Mbps)
SFP991-1
- 1x LC, multimode 5*
SFP991-1LD
- 1x LC, single-mode 26**
* With a cable cross-section of 50/125 μm or 62.5/125 μm; attenuation 1 dB/km at 1310 nm;
1200 MHz * km
** With a cable cross-section of 9/125 μm; attenuation ≤ 0.5 dB/km at 1310 nm
