Communications processors for PCs
7.1 CP 1604
Industrial Ethernet
System Manual, 09/2019, C79000-G8976-C242-10
301
Features
CP 1604
CP 1604 EEC
Required slot on the PC
PCI-104 (32-bit)
Number and type of the interfaces for Industrial Ethernet
4x RJ45
Gigabit Ethernet
-
Own microprocessor
Optional external power supply 12 ... 24 VDC
Functions
Up to 128 connections can be configured at one time
Transmission rates 10/100 Mbps (half/full duplex)
Autocrossover and autonegotiation
Ring redundancy with redundancy manager
IRT (Isochronous Real Time)
Network management and diagnostics using SNMP
Supported protocols:
ISO
TCP/UDP
PN
MRP
OPC
PG/OP
S7/S5
IT
● Suitable / available or according to the specified standard.
Article numbers
Component
Description
Article number
CP 1604 Communication processor PC/104 plus card (32-bit; 33/66 MHz;
3.3/5 V) with ASIC ERTEC 400 for connection to PROFINET IO
with 4-port real-time switch
6GK1160-4AA01
CP 1604 EEC Communication processor PC/104 plus card (32-bit; 33/66 MHz;
3.3/5 V) with ASIC ERTEC 400 for connection to PROFINET IO
with 4-port real-time switch, version suitable for railways
6GK1160-4AT01
