Siemens SIMATIC NET System Manual

Communications processors for SIMATIC S7
8.8 Communication processors for SIMATIC ET 200SP
Industrial Ethernet
342 System Manual, 09/2019, C79000-G8976-C242-10
Functions
The communication processors of this category support the following protocols and
technologies:
Protocol / function
CP 1542SP-1
CP 1542SP-1 IRC
CP 1543SP-1
TCP/UDP
●
●
●
IT
●
●
●
FTP
-
-
●
PG/OP ● ● ●
S7
●
●
●
DNP3
-
●
-
IEC 60870-5-104
-
●
-
SINAUT ST7
-
●
-
TeleControl Server
Basic (TCSB)
- ● -
IPv6
●
●
●
Firewall
-
-
●
VPN with IPsec
-
-
●
SNMPv1
●
●
●
SNMPv3
-
-
●
DCP
●
●
●
LLDP
●
●
●
NTP
●
●
●
● Suitable / available or according to the specified standard.
Article numbers
Device
Description
Article number
CP 1542SP-1 Communication processor for connecting a SIMATIC
S7-ET 200SP to Industrial Ethernet 1x 10/100 Mbps
RJ45 ports; TCP/IP, ISO-on-TCP, UDP, bus adapter
required (does not ship with the product)
6GK7542-6UX00-0XE0
CP 1542SP-1 IRC Communication processor for connecting a SIMATIC
S7-ET 200SP to Industrial Ethernet, SINAUT ST7,
TeleControl Server Basic, IEC-60870-5-104 or DNP3
protocol to a control center; TCP/IP, ISO-on-TCP, bus
adapter required (does not ship with the product)
6GK7542-6VX00-0XE0
CP 1543SP-1 Communication processor for connecting a SIMATIC
S7-ET 200SP to Industrial Ethernet, security function
firewall and VPN; TCP/IP, ISO-on-TCP, UDP, bus
adapter required (does not ship with the product)
6GK7543-6WX00-0XE0
