Basics of communication with Industrial Ethernet
1.3 Technologies of Industrial Ethernet
Industrial Ethernet
System Manual, 09/2019, C79000-G8976-C242-10
39
Cable type / transmission medium
Standard
Radio
(wireless)
N-Connect
R-SMA
SMA
QMA
IEEE 802.11/mobile wireless (2G, 3G, 4G)
Antenna cables (in each case standard cable and ca-
bles suitable for railway applications):
• N-Connect/R-SMA male/male flexible connection
cable for connecting antennas to SCALANCE W700
devices with R-SMA connector
• N-Connect male/male flexible connection cable e.g.
for connecting antennas to SCALANCE W devices
with N-Connector.
• N-Connect/SMA male/male flexible connection cable
for connecting antennas to SCALANCE M800 de-
vices
• QMA/N-Connect male/female adapter cable for
antennas with a QMA socket
Antennas:
• Antennas for IWLAN acc. to IEEE802.11n with 1
connector, 2 connectors or 3 connectors (MIMO)
• Antennas for mobile wireless (2G, 3G and 4G)
• IWLAN RCoax cable
Note
Cable installation
F
astConnect cables can be assembled particularly fast and simply on site. This means that
-45 cabling technology, an existing standard, is also available in a version suitable for
Product overview
You will find a detailed overview of the available modules and accessories in chapters 4 - 9.
Passive components for Industrial Ethernet and accessories
You will find an overview of the passive components as well as further accessories in the
system manual Industrial Ethernet/PROFINET Passive Network Components.
Passive components for IWLAN
You will find a detailed overview of the passive components in the "Passive network
components IWLAN" system manual.
