Basics of communication with Industrial Ethernet
1.3 Technologies of Industrial Ethernet
Industrial Ethernet
38 System Manual, 09/2019, C79000-G8976-C242-10
Table 1- 2 Passive network components for PROFINET/Industrial Ethernet
Cable type / transmission medium
Standard
Copper
(electrical)
RJ45 plug-in connect-
or
IE FC RJ-45 plug
90/145/180
M12 plug-in connector
D-coded, X-coded, A-
coded, L-coded
Two pair, symmetric and shielded copper cable:
IEC 61158
IE FC TP standard cable GP 2x2
IE FC TP robust standard cable GP2x2
IE FC TP flexible cable GP 2x2
IE FC TP robust flexible cable GP 2x2
IE FC TP trailing cable GP 2x2
IE FC festoon cable GP 2x2
IE FC TP food cable 2x2
IE TP torsion cable GP 2x2
IE TP train cable 2x2
IE FC TP trailing cable 2x2
IE FC TP marine cable 2x2
IE FC TP FRNC cable GP 2x2
IE TP ground cable 2x2
8-wire cable for Gigabit Ethernet:
IE FC TP standard cable (22 AWG) 4x2
IE FC TP standard cable GP (24 AWG) 4x2
Fiber-optic cable
(optical)
SC RJ plug
ISO/IEC 61754-24
POF FO cable (Plastic Optical Fiber)
PCF FO cable (Plastic Cladded Fiber)
ISO/IEC 60793-2-30
PCF standard cable GP
PCF trailing cable
PCF trailing cable GP (for SC RJ plug)
ST/BFOC (Bayonet
Fiber Optic Connector)
ISO/IEC 60874-10
SC plug
ISO/IEC 60874-14
LC connector
IEC 61754-20
Glass fiber cable - multimode fiber (62.5/125 µm)
ISO/IEC 60793-2-10
Fiber-optic standard cable
INDOOR fiber-optic indoor cable
Flexible fiber-optic trailing cable
SIENOPYR duplex FO marine cables (for ST/BFOC
Glass fiber cable - multimode fiber (50/125 µm)
ISO/IEC 60793-2-10
FO standard cable GP
FO trailing cable
FO trailing cable GP
FO Ground Cable (for ST/BFOC and SC connector)
