Siemens SINAMICS S120 - Connection Description; Overview

Line Connection Booksize
2.12 Line reactors for Basic Line Modules
Booksize power units
Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
111
2.12.3 Connection description
2.12.3.1 Overview
Figure 2-41 Line reactor for Basic Line Module (20 kW)
Figure 2-42 Line reactor for Basic Line Module (40 kW)
