Siemens SINAMICS S120 - Line;Power Connection

Line Connection Booksize
2.6 Wideband Line Filter for Active Line Modules
Booksize power units
58 Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
2.6.3.1 Line/power connection
Table 2-9 Type of connection
Terminals Designations
Line supply connection (line supply) L1, L2, L3, PE
Load connection (load) U, V, W
Wideband Line Filter for Active Line Modules
16 kW Screw terminal: 10 mm
2
3-pin/1.5 -1.8 Nm (see Screw Terminals chapter)
Grounding stud: M5/3 Nm
1)
36 and 55 kW Screw terminal: 50 mm
2
3-pin/6 - 8 Nm (see Screw Terminals chapter)
Grounding stud: M8/13 Nm
1)
80 kW Screw terminal: 95 mm
2
3–pin/15 - 20 Nm (see Screw Terminals chapter)
Grounding stud: M8/13 Nm
1)
120 kW Connection strap: d = 11 mm (M10/25 Nm)
Grounding stud: M8/13 Nm
1)
Note: No shock-hazard protection (IP00B acc. to 60529)
1) for ring cable lugs to DIN 46234
