Siemens SINAMICS S120 - Electrical Connection

Motor Modules Booksize
4.3 Motor Module with external air cooling
Booksize power units
366 Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
4.3.6 Electrical connection
Shield contact for the terminals
Figure 4-35 Shield contact for the terminals
(1) Shield connection: Weidmüller, Order No. KLBÜ 3-8 SC
Internet address
Weidmüller: http://www.weidmueller.com
NOTICE
Only use screws with a permissible mounting depth of 4-6 mm.
