Siemens SINAMICS S120 - Technical Data

Line Connection Booksize
2.6 Wideband Line Filter for Active Line Modules
Booksize power units
64 Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
2.6.5 Technical data
Table 2-11 Technical data: Wideband Line Filter for Active Line Modules
6SL3000
unit
0BE21-
6AAx
0BE23-
6AAx
0BE25-
5AAx
0BE28-
0AAx
0BE31-
2AAx
Rated power kW 16 36 55 80 120
Connection voltages:
Supply voltage
Line frequency
V
AC
Hz
3-ph. 380 V AC -10 % (-15 % < 1 min) up to 3-ph. 480 V AC +10 %
47 to 63 Hz
Rated current A
AC
30 67 103 150 225
Power loss
1)
W 70 90 110 150 200
Weight kg 8.5 14.5 15.5 26 34.5
1)
For an overview, see the power loss tables in chapter Cabinet Design
