6.2 Capacitor Module
Booksize power units
Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
419
6.2.6 Technical data
Table 6-7 Technical data
Capacitor Module
Electronics power supply V
DC
24 (20.4 - 28.8)
DC link voltage V
DC
510 - 720
Capacitance μF 4000
24 V DC busbar
current carrying capacity
A 20
DC link busbar current carrying
capacity
A 100
Power loss
1)
W 25
Weight kg 7.2
1)
For an overview, see the power loss tables in Chapter Cabinet design
