Line Connection Booksize
2.9 Active Interface Modules internal air cooling
Booksize power units
Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
85
2.9.3.3 Electronics power supply X124
Table 2-20 Terminal block X124
Terminal Function Technical specifications
+ Electronics power supply
+ Electronics power supply
M Electronic ground
+
M
M Electronic ground
Voltage: 24 V DC (20.4 V - 28.8 V)
Current consumption: max. 1.6 A
Max. current via jumper in connector:
20 A at 55 °C
Max. connectable cross-section: 2.5 mm
2
Note
The two "+" and "M" terminals are jumpered in the connector. This ensures the supply
voltage is looped through.
2.9.3.4 Line/power connection
Table 2-21 Type of connection
Terminals Designations
Line supply connection (line supply) L1, L2, L3
Load connection (load) U2, V2, W2
Active Interface Module
16 kW Connector IPC 16/3-STF-SH-10, 16; Cross-section 16 mm²
Tightening torque min. 1.7 Nm
36 kW Terminal type WGK 50 (Weidmüller), 50 mm² cross-section, ferrule
Tightening torque 6 Nm
55 kW Terminal type HDFK 50 , 50 mm² cross-section, ferrule
Tightening torque min. 6 Nm
80/120 kW Threaded bolt M8, max. cross-section 120/2 x 50 mm²,
tightening torque 13 Nm
1)
1) for ring cable lugs to DIN 46234
Note
The 55 kW Active Interface Module provides the IP20 degree of protection only with
insulated ferrule and a cross-section > 25 mm
2
.
