4.2.3.6 Meaning of the LEDs on the Motor Module
Table 4-5 Single Motor Module/Double Motor Module/Power Module - description of the LEDs
Status Description, cause Remedy
Ready (H200) DC link (H201)
OFF OFF Electronics power supply is missing or outside
permissible tolerance range.
–
OFF The component is ready for operation and cyclic
DRIVE-CLiQ communication is taking place.
–
Orange The component is ready for operation and cyclic
DRIVE-CLiQ communication is taking place.
The DC link voltage is present.
–
Green
Red The component is ready for operation and cyclic
DRIVE-CLiQ communication is taking place.
The DC link voltage is too high.
Check supply voltage
Orange Orange DRIVE-CLiQ communication is being established. –
Red – At least one fault is present in this component.
Note:
The LED is activated regardless of whether the
corresponding messages have been reconfigured.
Remedy and acknowledge
fault
Green/red
(0.5 Hz)
– Firmware is being downloaded. –
Green/red
(2 Hz)
- Firmware download is complete. Wait for POWER ON. Carry out a POWER ON
Green/orange
or
Red/orange
– Component detection via LED is activated (p0124).
Note:
Both options depend on the LED status when
component recognition is activated via p0124 = 1.
–
DANGER
Hazardous DC link voltages may be present at any time regardless of the status of the "DC
link" LED.
The warning information on the components must be carefully observed!
