Siemens SINAMICS S120 - Removing the DC Link Busbars; Mounting the Reinforced DC Link Busbars

Accessories
8.4 Reinforced DC-link busbars
Booksize power units
482 Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
8.4.4 Removing the DC link busbars
Unscrew the screws for the DC link busbar Remove the DC link busbars
Remove the DC link busbars on the adjacent components
too
View once the DC link busbars have been removed
8.4.5 Mounting the reinforced DC link busbars
Secure the reinforced DC link busbars Do not secure M4
screws tightly yet
Secure the reinforced DC link busbars on the adjacent
components too
Tightly secure all the M4 screws, 1.8 Nm +30 % With installed reinforced DC link busbars
