Motor Modules Booksize Compact
5.6 Electrical connection
Booksize power units
Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
393
5.6 5.6 Electrical connection
Shield contact for the terminals
Figure 5-10 Shield contact for the terminals
(1) Shield connection: Weidmüller, Order No. KLBÜ 3-8 SC
Internet address
Weidmüller: http://www.weidmueller.com
NOTICE
Only use screws with a permissible mounting depth of 4-6 mm.
