Line Connection Booksize
2.13 Line connection variants
Booksize power units
Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
137
2.13.3.9 Assignment of isolating transformers to Smart Line Modules
Table 2-51 Matching transformers with isolated windings for 50/60 Hz supply systems
Smart Line Module
5 kW 10 kW 16 kW 36 kW
Rated power [kVA] 21 47
Power loss, max. [W] 650 1200
Vector group Yyn0
Degree of protection acc. to
DIN EN 60529 (IEC 60529)
Degree of protection IP00: _ → Order No. 0
Humidity rating in accordance with
DIN EN 60721-3-3
Cl. 3K5, Condensation and icing excluded
Low air temperature 0 °C (+32 °F)
Permiss. ambient temperature
Operation [°C]
-25 to +40, for power de-rating up to +55, ISOKL: H, t
a
= 40
Approx. weight for
degree of protection IP00
120
200
Max. conn., secondary [mm
2
] 16 35
Input voltage, 3-ph. 575 V AC - 500 V AC - 480 V AC ± 10%; 50 Hz - 5% to 60 Hz + 5%
Rated input current [A] 26 58
Max. conn., primary [mm
2
] 16 35
Short-circuit voltage uk [%] 2.49 2.64
Order No. 4BU4395-0SA7_-0C 4BU4795-
0SC3_-0C
Input voltage, 3-ph. 440 V AC - 415 V AC - 400 V AC ± 10%; 50 Hz - 5% to 60 Hz + 5%
Rated input current [A] 31 69.5
Max. conn., primary [mm
2
] 16 35
Short-circuit voltage uk [%] 2.47 2.63
Order No. 4BU4395-0SA8_-0C 4BU4795-
0SC4_-0C
Input voltage, 3-ph. 240 V AC - 220 V AC - 200 V AC ± 10%; 50 Hz - 5% to 60 Hz + 5%
Rated input current [A] 62 138.5
Max. conn., primary [mm
2
] 35 70
Short-circuit voltage uk [%] 2.43 2.59
Order No. 4BU4395-0SB0_-0C 4BU4795-
0SC5_-0C
