Siemens SINAMICS S120 - Line;Power Connection

Line Connection Booksize
2.8 Basic Line Filter for Smart Line Modules
Booksize power units
Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
75
NOTICE
The line/load connection must not be interchanged.
Line voltage 415 V 3 AC to 480 V AC + 10 %
● Controlled DC link voltage required, or
● limitation of the DC link voltage required due to motor isolation
2.8.3.2 Line/power connection
Table 2-16 Type of connection
Terminals Designations
Line supply connection (line supply) L1, L2, L3, PE
Load connection (load) L1´, L2´, L3´, PE
Basic Line Filter for Smart Line Modules
5 kW
10 kW
16 kW
Screw terminal: 10 mm
2
3-pin/1.5 -1.8 Nm (see Screw Terminals chapter)
Grounding bolt: M6/6 Nm
1)
36 kW Screw terminal: 35 mm
2
Grounding bolt: : M6/6 Nm
1)
1) for ring cable lugs to DIN 46234
