System Overview
1.6 Power sections
Booksize power units
30 Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
1.6 1.6 Power sections
Line modules
Convert the three-phase supply into a DC voltage for the DC link.
● Smart line modules
The smart line modules generate a non-stabilized DC link voltage and are capable of
regenerative feedback.
● Active line modules
The active line modules generate a stabilized DC link voltage and are capable of
regenerative feedback.
● Basic Line Modules
Basic Line Modules generate an unregulated DC link voltage and are not capable of
regenerative feedback.
Motor modules
● Convert energy from the DC link for the connected motors with variable voltage and
variable frequency.
1.7 1.7 System data
Technical data
Unless explicitly specified otherwise, the following technical data are valid for components of
the SINAMICS S120 booksize drive system.
Electrical data
Line connection voltage 3-ph. 380 V to 480 V AC ±10%
(-15% < 1 min)
Line frequency 47 Hz to 63 Hz
Electronics power supply 24 V DC -15/+20%*, protective extra-low voltage DVC A
(PELV)
Short-circuit current rating SCCR in accordance with
UL508C (up to 600 V)
• 1.1 KW – 298 kW: 42 kA
• 299 kW – 447 kW: 65 kA
• 448 kW – 671 kW: 84 kA
• 672 kW – 1193 kW: 170 kA
• ≥ 1194 kW: 200 kA
Interference suppression
to EN 61800-3
Category C2 (optional)
for system versions conformant with documentation
Overvoltage category III acc. to EN 60664-1
Degree of contamination 2 to EN 60664-1
*
If a motor holding brake is used, restricted voltage tolerances (-2/+10%) may have to be taken into account.
