Siemens SINAMICS S120 - Line Supply;Load Connection

Line Connection Booksize
2.4 Basic Line Filter for Active Line Modules with line reactor
Booksize power units
44 Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
WARNING
The line/load connection must not be interchanged.
2.4.3.2 Line supply/load connection
Table 2-2 Type of connection
Terminals Designations
Line supply connection (line supply) L1, L2, L3, PE
Load connection (load) L1´, L2´, L3´, PE
Basic Line Filter for Active Line Modules
16 kW Screw terminal: 10 mm
2
3-pin/1.5 -1.8 Nm (see Screw Terminals chapter)
PE connection: M6/6 Nm
1)
36 kW Screw terminal: 35 mm
2
PE connection: M6/6 Nm
1)
55 kW Screw terminal: 50 mm
2
/6 - 8 Nm
PE connection: M6/6 Nm
1)
1) for ring cable lugs to DIN 46234
