Line Connection Booksize
2.13 Line connection variants
Booksize power units
Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
131
Table 2-47 Autotransformers for 220 V input voltage
Smart Line Module
5 kW /10 kW /16 kW 36 kW
Rated power [kVA]
Autotransformer IP00
21
46.5
Input voltage [V] 220 V AC 3-phase ± 10%; 50 Hz - 5% to 60 Hz + 5%
Output voltage [V] 400 V AC, 3-phase
Vector group Yna0
Permiss. ambient temperature
Operation [°C]
-25 to +40, for power de-rating up to +55 °C, ISOKL: H, t
a
= 40
Humidity rating in accordance with DIN
EN 60721-3-3
Cl. 3K5, Condensation and icing excluded
Low air temperature 0 °C (+32 °F)
Degree of protection to EN 60529
(IEC 60529) IP00
Degree of protection IP00: _ → Order No. 0
Order No. 4AU3696-0ER30-2XA0 4BU4395-0CB6_-8B
Power loss [W]
Autotransformer IP00
550
900
Short-circuit voltage uk [%] ≤ 1.5
Conn. cross-section, max.
primary/secondary sides
16/16 mm
2
70/50 mm
2
Fuse, primary side 63 A gL 160 A gL
Weight [kg], approx. for
Degree of protection IP00
57
110
Terminal arrangement 1U1 to 1W1 = 220 V input, 2U1 to 2W1 = 400 V output, N = neutral point
