Line Modules Booksize
3.6 Smart Line Modules (16 kW und 36 kW) with internal air cooling
Booksize power units
Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
273
Internal air cooling 6SL3130– 6TE21-6ABx 6TE23-6ABx
Rated power kW 16 36
Circuit-breaker type designation
(status 07/2007 and later)
Rated current
Short-circuit current rating SCCR at 400 V
AC
A
kA
3RV1042-4FA10
28 ... 40
100
3RV1042-4LA10
70 ... 90
100
Circuit-breaker type designation
UL489/CSA C22.2 No. 5-02
Rated current
Rated short circuit current SCCR
A
kA
-- 3VL2108-3KN30-0AA0
80
65
UL safety fuse type AJT Class J
Rated current
Short-circuit current rating SCCR at 600 V
AC
A
kA
AJT35
35
200
AJT80
80
200
Safety fuses NH
Rated current A
3NA3 814
35
3NA3 824
80
Cooling method (internal air cooling) Internal fan Internal fan
Sound pressure level dB(A) <60 <65
Cooling air requirement m
3
/h 56 112
Rated voltage for rated data 380 V 3 AC
Weight kg 7 10
1)
The specified values apply to 380 V
2)
For an overview, see the power loss tables in Cabinet Design chapter.
