Line Modules Booksize
3.7 Smart Line Modules Booksize Compact
Booksize power units
Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
291
Smart Line Module Booksize Compact 6SL3430– 6TE21-6AAx
Rated power kW 16
Circuit-breaker type designation
(status 06/2007)
Rated current
Short-circuit current rating SCCR at 400 V
AC
A
kA
3RV1031-4FA10
28 ... 40
50
UL safety fuse type AJT Class J
Rated current
Short-circuit current rating SCCR at 600 V
AC
A
kA
AJT35
35
200
Safety fuses NH
Rated current A
3NA3 814
35
Cooling methods Internal air cooling/
cold-plate cooling
Cooling air requirement with internal air cooling m
3
/h 56
Max. permissible heat sink temperature cold
plate
°C 70
Sound pressure level dB(A) <60
Total cable length m 350 (shielded)
560 (unshielded))
Weight kg 5.3
1)
The specified values apply to 380 V
2)
For an overview, see the power loss tables in Cabinet Design chapter.
